How to install a goalrilla basketball system
Basketball Hoop Installation – Goalrilla
INSTALLING YOUR GOAL
Never installed a basketball goal before and not sure where to start? Not a problem. Regardless of where you purchased your hoop, you’ll have the option of installing it yourself or paying a professional to do it for you. The following article will walk you through the steps.
The following videos will walk you step-by-step through the process of installing an in-ground basketball goal.
Installing the anchor kit
Part 2
Goal Installation
MIXING CONCRETE FOR AN IN-GROUND INSTALLATION
The secret to a long-lasting basketball hoop is in foundation. Achieving the correct mixture of dry concrete and water can give your goal additional years of life!
A mixture that is too thin lacks the strength needed to properly hold the steel pole in place. A mixture that is too thick will leave you struggling to fill voids that can’t be seen below, again compromising strength. So how do you achieve the perfect balance? Let’s find out!
Compressive Strength
Concrete is rated by its compressive strength, which means: how much pressure per square inch can a standard cylinder of concrete withstand before breaking. These ratings are derived from standardized machines which can evenly apply pressure across the surface of a concrete cylinder.
Compressive strength is largely determined by the composition of the mix. Walk into any home improvement store and you’ll see a variety of mixes that advertise ‘fast setting,’ ‘high-strength,’ ‘crack resistant,’ etc. The main difference between each of these is some mixes may contain additional ingredients, such as fiberglass, to provide even greater bond strength.
If you have a specific mix you’re looking for, then great, you already know what to get. However, if you’re simply trying to follow the instructions for your hoop, your standard ‘High-Strength’ mix will do just fine.
What Does Goalrilla Recommend?
Goalrilla recommends purchasing 12-13 bags of Quikrete concrete mix. This concrete meets the ASTM C387 Standard Specifications for concrete.
While directions state you only need 11 bags, it’s not a bad idea to have an extra bag or two on hand in the event the installation gets a little messy. As you’ll find out, concrete mix can be difficult to move and it’s very easy to accidentally tear a bag open.
Mixing the Concrete
Once you have all the appropriate materials, start by opening 1-2 bags and pouring them into a large container. Add water according to what the instructions dictate.
For an 80 lb. bag, you’ll want to use 6 pints or 2.8 L of water, or for a 60 lb. bag, you’ll want to use 4 pints or 1. 9 L per bag of concrete. If you don’t have measuring bucket around, a 2 L soda pop bottle will work to get a close enough estimation.
Create a depression in the center of the dry mix and add your water here. Work the mix with a hoe or other tool and ensure consistency across the batch. Properly mixed concrete should be wet, but firm enough to hold its shape and in an oatmeal-like consistency. You can test its consistency by picking up a handful while wearing gloves.
Do not let the mix sit for extended periods of time or you run the risk of letting it dry out. Move the mix to the freshly dug hole as soon as possible and agitate as you pour to help alleviate any voids. A trench shovel and extra set of hands will be helpful here.
On especially hot days you may need to add more water to the mix as water will evaporate. Always keep the mix moving and ensure the mix maintains its consistency.
Repeat these steps as necessary until you have the appropriate amount of concrete.
Pouring Concrete in Cold Weather
Installing your basketball hoop in winter is possible but has a few caveats. If the outside temperature is below 40° F (4.44° C) for an extended period of time, you will want to reconsider your install date. Temperatures below this threshold can cause all sorts of problems your average DIY installer is most likely not equipped to handle, nor would want to.
If you choose to pour concrete during the winter months, there are few things you or your installer will want to remember.
If the ground is frozen, you will need to wait until it thaws before you can even consider starting. You should NEVER place concrete in frozen ground, since it poses a number of problems from cracking, crusting, and settling unevenly.
Use a fast-setting mix with hot water. As the name implies, a fast-setting mix will usually set in under an hour. While it may set in under an hour, it will still take several days to cure. When mixing concrete in these temperatures, regardless of type, use hot water.
Use an accelerator. If you don’t have access to fast-setting concrete or have already purchased regular concrete, you can purchase an accelerator that helps increase the concrete hydration rate. This helps to shorten the setting time and gets the concrete to a higher strength earlier. Avoid any accelerators or additives containing calcium chloride as this will cause the rebar to rust and could potentially cause the concrete to crack. Do not mix fast-setting concrete and an accelerator.
Use curing blankets. Specifically, for cold-weather applications, concrete curing blankets help to trap in the heat and moisture, so the concrete can reach its proper strength. Additionally, these “blankets” protect the concrete from freezing. Blankets can be purchased from your local home improvement store for around $50-$60 depending on your area. Keep in mind they do not look like the blankets you would use in your home. These blankets look more tarp-like and usually come in rolls.
In addition to these tips, some professional installers may have other methods or tricks they use to set concrete in colder weather. In this case, it may be better to hire a professional to do the job as they will often have the necessary supplies, like curing blankets, already on hand.
As the cost of additional materials begins to add up, combined with the inconvenience of working in the cold, you may find it’s better to have someone else do it.
The recommended hole size is 16 inches in diameter and 48 inches deep. You will need eleven 80-lb bags of concrete for the installation.
IMPORTANT SAFETY PRECAUTION: Before you dig, call your local utilities to rule out the presence of buried cables including power, water, gas and phone lines. Failure to do so could result in serious or fatal injury.
For safety purposes, we recommend you have at least three capable persons to assist you.
For best results with less vibration, your Goalrilla Anchor System should be independent of your court. If pouring concrete for both at the same time, add an expansion joint in between.
The anchor system is set in concrete on Day 1 and requires at least 72 hours to cure. We recommend erecting your system on Day 5 to ensure the superior rock-solid performance for which Goalrilla is famous.
Too much overhang can reduce the amount of court space and cause excessive shaking due to the weight of the backboard being suspended too far from the main pole. Look for approximately 2 feet to 4 feet of overhang for the best balance of safety and performance. A basketball hoop with an overhang of 5 feet or more can compromise performance because the weight of the glass backboard will increase shake in the system. A basketball hoop with an overhang of 5 feet will actually encroach on the play surface by more than 7 feet once you add the 25 inches of rim that come out from the backboard surface.
Overhang changes as the basketball goal is adjusted. Goalrilla basketball hoops are adjustable from the safety-approved height of 7. 5 feet to the NBA and NCAA regulation height of 10 feet. Use the Goalrilla basketball goal overhang chart here to find your model and learn the distance in overhang at each height.
Not feeling up to the job? You can always hire a professional to install your basketball hoop for you. While you might be tempted to call a local construction company or handyman, and although some of these businesses might offer basketball goal installation, we recommend contacting a Goalrilla installation specialist. Installing a goal requires exact precision and specialized processes to ensure your goal is level and operating at peak performance. No one knows how to do this better than a Goalrilla specialist!
CHECK FOR GOALRILLA AUTHORIZED DEALERS
Step one should always be to see if there is an authorized dealer in your area, particularly a Goalrilla Platinum Dealer. Goalrillas are sold through a network of full service dealers throughout the country, and these Goalrilla specialists can not only help you find the best goal to purchase, but they can install it too. These dealers are installing hundreds of Goalrillas every year, and know our exact specifications, so you can trust that they will get it done right!
OTHER INSTALLERS TO CONSIDER
For some people living in more remote areas of the country, you may not have a Goalrilla dealer nearby. In that case, you might opt to purchase your Goalrilla online. Luckily, you can still find an installer by performing a Google search of “National installation and assembly service.” That will give you a good place to start.
If you don’t have a local Goalrilla dealer or installer in your area, then you may consider contacting a general contractor. A simple Google search for “basketball goal installers + [YOUR CITY],” should turn up some places to start. In this case, you may want to direct this service provider to our installation guide to make sure they have the correct information for a successful installation.
HOW MUCH SHOULD IT COST?
Managing the installation yourself has its own merit, but if you’re paying somebody to do it, you should expect professional quality. Professional installations should generally range anywhere from $400 to $600 from beginning to end. Especially if you are working with an installation company or local contractor, be sure to get a couple different quotes before committing to a purchase.
If you are considering a service provider that is not a Goalrilla authorized dealer for the installation of your basketball goal, you may want to consider asking the following questions…
This is by far the most important question to ask when evaluating an installer. It’s a no-brainer that if someone hasn’t done many other installations, you probably don’t want to be their first guinea pig. Most professional installers will have a gallery on their website showcasing their work. If they do not, it may be a good idea to see if they have a Facebook or other social media page where these photos are posted.
Installing a full in-ground system is a multi-step, multi-day process. The first day involves digging the hole and installing the concrete, followed by 3 days for the concrete to cure, and then final assembly of the goal. Make sure the quote you receive covers the concrete installation AND the assembly of the goal, as well as the materials to do the job.
Most installers have multiple projects running simultaneously, and this is especially true during the spring and summer months. You will likely not be the only project on the schedule.
Before committing to the installation, be sure to find out when they will start and when it will be completed. The installation for any Goalrilla will take at least 4 days, and a particularly busy installation schedule may delay your install date even further. Make sure your selected installer can get your goal installed in a timeline that works for you, so you can start playing as soon as possible!
Disregarding an installer’s other jobs, an installation may take more than 4 days depending on the weather. The concrete takes 3 days to cure in warm temperatures, so when the mercury begins to drop, the curing process can take significantly longer. Additionally, if the ground is frozen, it’ll be almost impossible to dig a hole.
More on cold-weather installations can be learned here. Be sure to discuss these conditions and other alternative options with the installer.
A botched installation can cause you and your family a lot of frustration and money. Check with the installer to see what their warranty policy is in the event of an error in installation. Be sure to make a note on the specifics of the warranty and get a copy if possible. If after the installation something seems wrong, immediately take notes and pictures to have as documentation when calling.
<>Accidents do happen and when there’s a several hundred-pound steel pole or backboard involved, the severity of some accidents can escalate quickly. If an independent contractor (aka the installer) ends up getting injured while doing an installation on your property, you could be responsible.
This is one of the major reasons hiring a professional from a reputable company is a must for this type of project. A reputable company will carry insurance for these types of accidents and injuries, so you don’t have to worry about a lawsuit. Always be sure to ask before agreeing to any installation and see the certificate of insurance for general liability.
For some people, there may be additional steps you need to take before an installer can begin work. The major task that needs to be completed is having the utility lines marked. Since there is a 4-foot deep hole that must be dug at the installation site, you and the installer need to be aware of any buried cables. Call 811 at least a few days ahead of the dig date to have the cables marked.
Additionally, most installers will need to have the area around the installation mowed, the driveway free of any cars, toys, or other debris, and the boxed goal easily accessible at the installation site (If you purchase your goal from a Goalrilla authorized dealer, they will likely deliver the goal themselves for installation).
Also, be sure to ask the installer if you need to be present for the installation. Even if you don’t have to be, being on-site during installation can help to resolve any questions that may arise.
Once the goal installed, there are a few final clean-up notes to consider. Be sure to ask how any excess dirt will be handled or disposed of. If you would like to reuse the dirt, agree upon where the excess dirt will be placed. A request to have the dirt placed on the side of the house or in a designated corner in the backyard shouldn’t be a problem.
Also, if you purchased your Goalrilla goal online, it will be delivered on a pallet via a freight shipment. Ask if your installer can take care of disposing of this pallet as well.
Find A Local Installer
Not feeling up to the job yourself? No problem. View our list below of Goalrilla basketball goal installers to get the help you need.
Store locator is loading from StoreRocket Store Locator Widget..
maintenance
In the following blog post, we will share basketball court ideas, basketball court dimensions, and basketball court size so you could start playing. ..
Read more
maintenance
After purchasing a Goalrilla basketball goal online from our website, here are the steps to expect.
Read more
maintenance
It’s important to know how to store your basketball goal and its accessories in the winter. Read our tips here!
Read more
How to Install a Basketball Hoop
Save $350 off + USE CODE SCORE TO GET A FREE GIFT WITH SBX60 HOOP PURCHASE
Shop Now
Dealer Locator
The following videos will walk you step-by-step through the process of installing an in-ground basketball goal.
Installing the anchor kit
Part 2
Goal Installation
MIXING CONCRETE FOR AN IN-GROUND INSTALLATION
The secret to a long-lasting basketball hoop is in foundation. Achieving the correct mixture of dry concrete and water can give your goal additional years of life!
A mixture that is too thin lacks the strength needed to properly hold the steel pole in place. A mixture that is too thick will leave you struggling to fill voids that can’t be seen below, again compromising strength. So how do you achieve the perfect balance? Let’s find out!
Compressive Strength
Concrete is rated by its compressive strength, which means: how much pressure per square inch can a standard cylinder of concrete withstand before breaking. These ratings are derived from standardized machines which can evenly apply pressure across the surface of a concrete cylinder.
Compressive strength is largely determined by the composition of the mix. Walk into any home improvement store and you’ll see a variety of mixes that advertise ‘fast setting,’ ‘high-strength,’ ‘crack resistant,’ etc. The main difference between each of these is some mixes may contain additional ingredients, such as fiberglass, to provide even greater bond strength.
If you have a specific mix you’re looking for, then great, you already know what to get. However, if you’re simply trying to follow the instructions for your hoop, your standard ‘High-Strength’ mix will do just fine.
What Does Goalrilla Recommend?
Goalrilla recommends purchasing 12-13 bags of Quikrete concrete mix. This concrete meets the ASTM C387 Standard Specifications for concrete.
While directions state you only need 11 bags, it’s not a bad idea to have an extra bag or two on hand in the event the installation gets a little messy. As you’ll find out, concrete mix can be difficult to move and it’s very easy to accidentally tear a bag open.
Mixing the Concrete
Once you have all the appropriate materials, start by opening 1-2 bags and pouring them into a large container. Add water according to what the instructions dictate.
For an 80 lb. bag, you’ll want to use 6 pints or 2.8 L of water, or for a 60 lb. bag, you’ll want to use 4 pints or 1.9 L per bag of concrete. If you don’t have measuring bucket around, a 2 L soda pop bottle will work to get a close enough estimation.
Create a depression in the center of the dry mix and add your water here. Work the mix with a hoe or other tool and ensure consistency across the batch. Properly mixed concrete should be wet, but firm enough to hold its shape and in an oatmeal-like consistency. You can test its consistency by picking up a handful while wearing gloves.
Do not let the mix sit for extended periods of time or you run the risk of letting it dry out. Move the mix to the freshly dug hole as soon as possible and agitate as you pour to help alleviate any voids. A trench shovel and extra set of hands will be helpful here.
On especially hot days you may need to add more water to the mix as water will evaporate. Always keep the mix moving and ensure the mix maintains its consistency.
Repeat these steps as necessary until you have the appropriate amount of concrete.
Pouring Concrete in Cold Weather
Installing your basketball hoop in winter is possible but has a few caveats. If the outside temperature is below 40° F (4.44° C) for an extended period of time, you will want to reconsider your install date. Temperatures below this threshold can cause all sorts of problems your average DIY installer is most likely not equipped to handle, nor would want to.
If you choose to pour concrete during the winter months, there are few things you or your installer will want to remember.
If the ground is frozen, you will need to wait until it thaws before you can even consider starting. You should NEVER place concrete in frozen ground, since it poses a number of problems from cracking, crusting, and settling unevenly.
Use a fast-setting mix with hot water. As the name implies, a fast-setting mix will usually set in under an hour. While it may set in under an hour, it will still take several days to cure. When mixing concrete in these temperatures, regardless of type, use hot water.
Use an accelerator. If you don’t have access to fast-setting concrete or have already purchased regular concrete, you can purchase an accelerator that helps increase the concrete hydration rate. This helps to shorten the setting time and gets the concrete to a higher strength earlier. Avoid any accelerators or additives containing calcium chloride as this will cause the rebar to rust and could potentially cause the concrete to crack. Do not mix fast-setting concrete and an accelerator.
Use curing blankets. Specifically, for cold-weather applications, concrete curing blankets help to trap in the heat and moisture, so the concrete can reach its proper strength. Additionally, these “blankets” protect the concrete from freezing. Blankets can be purchased from your local home improvement store for around $50-$60 depending on your area. Keep in mind they do not look like the blankets you would use in your home. These blankets look more tarp-like and usually come in rolls.
In addition to these tips, some professional installers may have other methods or tricks they use to set concrete in colder weather. In this case, it may be better to hire a professional to do the job as they will often have the necessary supplies, like curing blankets, already on hand.
As the cost of additional materials begins to add up, combined with the inconvenience of working in the cold, you may find it’s better to have someone else do it.
STEP 1 These instructions detail whether or not to place the return unit on the right side when you are seated at a desk. If you want the return to be positioned on the left, you will need to reposition the elements accordingly.
Insert three additional cams and cams in the additional positions provided. (Two at the bottom of the worktop and back and one extra each at the side and back)
IMPORTANT:
STEP 2
returned. This makes it easier to install the returned block. After attaching the returned unit to the top of the tabletop unit, install the optional third flat surface back onto the backplate of the returned unit and the table leg. Secure all brackets with four screws each. Once the returned unit has been properly installed, cover any open Klix chambers with the supplied stickers.
STEP 3
IMPORTANT NOTE:
Place all laminated parts on a clean and smooth surface such as a rug or carpet to avoid scratching them.
Make sure you have all parts and equipment.
Before assembly, remove all packing materials, including staples and packing straps.
Do not tighten all screws/bolts until the parts are fully assembled.
Keep all parts of the equipment out of the reach of children.
2 people are recommended to complete the assembly.
instructions
CALL US! DO NOT RETURN TO THE STORE. For immediate assembly assistance or product information, call our toll-free number: 1-888-598-7316 Mon. - Fri. 7 AM to 7 PM (Central Standard Time) Our staff is ready to help. Damaged or missing parts ship from our facility within 1-2 business days. Please provide the following information:
Full Name
Physical Address - Please do not include a PO Box as our carriers cannot deliver to PO Boxes.
Phone number
Model number
Part number
Invoice #
Purchase date
Note. Our policy is to send all requests for parts by regular ground transportation. If you would like these parts delivered overnight/next day, please provide your designated carrier and account number. Replacement panels are not available. If any damage occurs during shipping, return the entire unit to the place of purchase for a refund and replacement. An original invoice may be required. Before you begin: Open, identify and count all parts before assembly. Lay the parts out on a non-abrasive surface such as a rug or blanket. 9388 Reversible return hood, 69389 Reversible return hood, 69421 Reversible return hood, 69422 Reversible return hood, 69423 Reversible return hood, 69554 Reversible return hood, 69555 Reversible return hood, 69594 Reversible return hood, 69 return hood, 69979 Reversible return hood068 LORELL, Reversible Return Shroud
Basketball hoop height and fitting - Article
Back in the 19th century, basketball had rules similar to today's. The teams had to throw the ball into the ring, located at a certain height, each had its own zone and basket. For a certain period of time, it was necessary to throw the ball into the ring as many times as possible. The team that scored the most goals won.
There were also certain rules for dribbling. Penalties were imposed for violations. The size of the basketball hoop at that time was not strictly regulated. Traditional fruit baskets were used as baskets.
With the development of basketball as a sport, the bottom of the basket began to be removed so as not to waste time constantly reaching for the ball. The shape of the ball was also not perfect.
Baskets were often hung on balconies, and the people sitting on them prevented the ball from flying freely. This was one of the reasons for the invention of the basketball backboard. With this specific design, the players were somehow protected from the fans. Later, the athletes drew attention to the fact that throwing the ball is also possible when rebounding from the shield.
Basketball hoop parameters
Hoop height and dimensions have changed little over time. Fruit baskets have ceased to be used since 1893 . From this period, they were replaced by metal rings, and in order to exclude disputes about hitting the ball, they began to hang the net down. It made it possible to more accurately determine whether the ball hit the basket. From to 1894 , uniform rules began to operate in basketball.
This game quickly became popular in the world and especially in the USA. Professional players began to be highly valued in the sports world, and the value of their contracts began to be measured in large amounts, even when an athlete was on the field for a short time. Large earnings allowed athletes to train well, developing skills and abilities of the game.
It is important for professional players to use special equipment during training, namely a basketball hoop of a certain size, set at a certain height. This makes it possible to hone the power of the throw and accurately calculate the trajectory of the ball.
It was decided in 1893 to bring inventory to uniform standards together with the rules.
Modern basketball baskets must comply with the following parameters:
diameter of the rod for the ring - from 16 to 20 mm;
mesh with a diameter of 450 mm, with cells - 50 mm;
the lower part of the shield at a level of 290 cm from the floor;
when playing indoors, the ceiling height is more than 7 meters;
game board dimensions - 180x105 cm;
dimensions of the playing field 28x15 m;
ring diameter - from 45 to 45.7 cm;
basket location - 305 cm from the floor, i.e. 15 cm above the bottom of the shield.
The size of the ball is also strictly regulated. For male and female teams these sizes are different:
for basketball players : in diameter - 74.9-78 cm with a weight of 567 to 650 g;
9 L per bag of concrete. If you don’t have measuring bucket around, a 2 L soda pop bottle will work to get a close enough estimation.
When mixing concrete in these temperatures, regardless of type, use hot water.
These blankets look more tarp-like and usually come in rolls.
If pouring concrete for both at the same time, add an expansion joint in between.
5 feet to the NBA and NCAA regulation height of 10 feet. Use the Goalrilla basketball goal overhang chart here to find your model and learn the distance in overhang at each height.
These dealers are installing hundreds of Goalrillas every year, and know our exact specifications, so you can trust that they will get it done right!
Professional installations should generally range anywhere from $400 to $600 from beginning to end. Especially if you are working with an installation company or local contractor, be sure to get a couple different quotes before committing to a purchase.
Make sure the quote you receive covers the concrete installation AND the assembly of the goal, as well as the materials to do the job.
Always be sure to ask before agreeing to any installation and see the certificate of insurance for general liability.
..
Walk into any home improvement store and you’ll see a variety of mixes that advertise ‘fast setting,’ ‘high-strength,’ ‘crack resistant,’ etc. The main difference between each of these is some mixes may contain additional ingredients, such as fiberglass, to provide even greater bond strength.
Add water according to what the instructions dictate.
Always keep the mix moving and ensure the mix maintains its consistency.
As the name implies, a fast-setting mix will usually set in under an hour. While it may set in under an hour, it will still take several days to cure. When mixing concrete in these temperatures, regardless of type, use hot water.
Blankets can be purchased from your local home improvement store for around $50-$60 depending on your area. Keep in mind they do not look like the blankets you would use in your home. These blankets look more tarp-like and usually come in rolls.
If you want the return to be positioned on the left, you will need to reposition the elements accordingly.
Our policy is to send all requests for parts by regular ground transportation. If you would like these parts delivered overnight/next day, please provide your designated carrier and account number. Replacement panels are not available. If any damage occurs during shipping, return the entire unit to the place of purchase for a refund and replacement. An original invoice may be required.
For a certain period of time, it was necessary to throw the ball into the ring as many times as possible. The team that scored the most goals won.
Fruit baskets have ceased to be used since 1893 . From this period, they were replaced by metal rings, and in order to exclude disputes about hitting the ball, they began to hang the net down. It made it possible to more accurately determine whether the ball hit the basket. From to 1894 , uniform rules began to operate in basketball.
